Vitrified bonded CBN grinding tools for machining camshafts are extremely economical. They are of the highest quality and are well designed for each applicationsuch as Cam lobe grinding and journal grinding. Optimized surface quality, roundness, straightness and conicity can easily be achieved.
CBN CAMSHAFT G/Wheel's Specs and Condition for Use
| Work Piece | Condition | Hardness | Spec |
| Camshaft | FC25 | HB 201-262 | CBN 80 M 220V |
| FCD | HRC 54-63 | CBN 100 M 200V | |
| Camshaft Cam | GGG60 | HRC 60 | CBN 80 M 200 V |
| Camshaft Cam Profile | Alloy Steel | HRC 60 | CBN 120 M 200 V |
| Fuel Injection Cam | SCM415 | HRC 54-63 | CBN 80 M 200 V |
| Camshaft Lobe | Hardened Alloy Steel | HRC 58-60 | CBN 80 M 220 V |
